Functions and features

1.Automatic counting points, the whole line of the output.

2.Spiral blade shear, vacuum adsorption folds.

3.Put volume stepless speed regulation, can adapt to high and low tension of base paper.

4.Electronically controlled pneumatic, easy to operate.

5.Product width can be adjusted to facilitate customer marketing.

6.Rolling paper pattern matching device, the pattern is clear that flexible market demand. (Selected pattern set by the guests).

7.Form a complete set of two-color flexo printing device, colorful patterns.

The working principle of tissue cutting

Cutting system：Consist of sawing belt, belt wheel, working panels.Work panels have product size adjustment device, adjustable make the product to achieve.

Folding forming: Along with the main motor running, fold the crank arm manipulator rod body, cooperate to produce, the deflection Angle, can adjust the position of the crank arm and change the length of the connecting rod to adjust (after folding forming is solid, i.e., don't need to adjust)

Dislocations counting and dividing：Adjust budget Numbers count control instrument, when the number reaches a constant value, relay drive cylinder to produce finished products export bedplate of displacement.

The characteristics of the tissue machine：

    Have put roll tension control,,can adapt to high and low tension base paper production. In the paper can roll pattern, pattern is clear. Facial tissue machine adopts stepless speed regulation, conveyor, embossing, flowers; Vacuum folding, cutting.



Model	YJ-2L          YJ-3L             YJ-4L              YJ-5L             YJ-6L
Width of the base paper	420mm        630mm          840mm        1050mm           1260mm
Base paper gram	12-18g/m x 2-3layers
Base paper diameter	Standard φ1100mm
The paper core diameter	3’(76.2mm)
The finished product size	（140,150,160-210）x（140-210）(mm)
Folding size	(70-105)x(140-210)(mm)
Production speed	1600              2400             3200              4000                4800
The machine drive	CVT system
Program control	PLC, touch screen
Pressure side of the system	Steel on steel, independent adjustment
Counting System	Dislocations pile of counting
Pneumatic system	3 air compressor, at least 5 kg/cm2Pa pressure
Mechanical speed	60-100m/min
Fan system	5.5kw              7.5kw              11kw            13.5kw           16kw
Power	2.2kw               3kw                4kw              5.5kw             7.5kw
Installation dimensions	4.1x1.3x2.1         4.1x1.5x2.1          4.1x1.7x2.1          4.1x2x2.1         4.1x2.3x2.1
Machine weight	1.8T                  2.2T                2.6T              3.0 T             3.5T
